Network-Connected Safe Lock
ProLogic WebLink - Direct Connect
Hard-Wired. Centralized. Secure.
A network-connected safe lock system designed for commercial and banking environments that require direct Ethernet connectivity, centralized control, and audit-ready oversight.
ProLogic WebLink Direct Connect integrates into your secure network using an IP Box, enabling remote programming, lock management, and real-time audit tracking through WebLink software.
PROLOGIC WEBLINK – DIRECT CONNECT
Features
- Hard-wired network connection via IP Box
- Remote programming and lock management using WebLink software
- Supports up to 99 users with Super Code setup
- 8-digit access codes for enhanced security
- 1,000-event audit trail on lock with unlimited history in software
- Time Lock with up to 4 schedules per day
- Configurable Time Delay and Time Window protection
- One-Time Code capability
- Date-based access codes
- Single or Dual Control operation modes
- Dual Manager Mode for two-person access control
- Lock sequencing for up to 5 locks
- AC-powered with battery backup
- Compatible with SECURAM SwingBolt, DeadBolt, and SpringBolt options
Specifications
- Connectivity: IP Box required (hard-wired Ethernet)
- Code Length: 8 digits
- Audit Capacity: 1,000 events stored on lock
- Power Supply: AC power with battery backup
- Battery Life: Approximately one year
- Operating Humidity: Up to 90%
System Components
EntryPad
- ProLogic WebLink Direct Connect EntryPad (N90)
Part #: EC-2001A-W90-II-N-OTC-CCH
Compatible Bolt Options
- SwingBolt with Bolt Status – Part #: EL-0601-S-V5
- DeadBolt with Bolt Status – Part #: EL-0701
- SpringBolt with Bolt Status – Part #: EL-0801
Required Accessories
- WebLink IP Box – Part #: CB22-A-1T5-N
- AC/DC 9V Power Adapter – Part #: ACDC9-10
- 4-Wire Communication Cable – length varies by installation
Software
- WebLink Remote Management Software (PC-based)
Part #: WSK-WebLink
Direct Connect vs. Wireless: Designed for environments where hard-wired network connectivity is required or preferred.
What’s Required to Operate
- ProLogic WebLink Direct Connect EntryPad
- One compatible SECURAM lock body
- WebLink IP Box for hard-wired network connection
- WebLink Remote Management Software (PC-based)
- Power and communication accessories
Resources
Built for Commercial Security
Advanced Access Control
Centralized management, secure network integration, and audit-ready oversight for demanding commercial environments.
Centralized Control
Manage Every Lock from One Platform
Program users, manage access, and review audit activity remotely using WebLink software.
Network-Connected Security
Designed for Secure Infrastructure
Integrates into your secure network with encrypted communication for reliable, enterprise-grade protection.
Built for Commercial Operations
Made for Multi-Location Management
Ideal for businesses managing multiple safes, locations, or teams with consistent access policies.
Accountability & Oversight
Visibility You Can Trust
Track access events, enforce dual control, and maintain audit accountability across your operation.
Video
Learn About WebLink Wireless
Wireless Network Option
For applications that prefer wireless connectivity, WebLink Wireless offers centralized lock management through a Wireless Access Point—providing flexibility without hard-wired network requirements.
Learn MoreCommercial Lock Options
Secure lock solutions designed for commercial and professional environments.
